Gross Power: 1650 HP
Power available for traction: 1500 HP
Total Weight (fully fueled): 80,000 kg
Weight per axle (fully fueled): 20,000 kg
Maximum Traction Effort: 20,500 kgf
Maximum Speed: 68 km/h
Brake Equipment Type: 26 LA / 6 SL-M / 26L
Minimum Inscription Radius: 58.82 m
Fuel Tank Capacity: 4,000 L
Lubricating Oil Capacity (crankcase): 625 L
Dynamic Braking: Optional
Length between hitches: 14,376 mm
Width: 2,819 mm
Height: 4,000 mm
Gauge: 1.00 m / 1.60 m
Traction Control: WS relay / electronic microprocessor
Type: Lead-acid
Voltage: 64V
Capacity: 135 Ah
Model: 645-E
Number of Cylinders: 12
Cylinder Arrangement: 45° "V""
Operating Principle: 2-Stroke
Washing: Blower
Cooling: Water
Trick Class: BB
Gear Ratio: 63-14
Axle Sleeves: 5.1/2"x10" | 6.1/2"x12""
Bearing Type: "HYATT" / RBU Housing
Type of Drive Wheels: A-40 / CE40
Model: WXOV / WBO
Cooling System: Air / Water
Model: D-29 / D-31
Type: CC.
Maximum Intensity: 450 A / 520 A
Quantity per Locomotive: 04
Main Generator Model: D-12 / D-22
Rated Voltage (DC): 600 V
Maximum Intensity: 1400 - 1600 A / 1600 - 2000 A
Power: 10 / 18 kW
